Street/Track EG - The build by Foy.

[lil_foy]

Hey guys, I know a few of you on here but i've never really posted anything relating to my civic on here. Whilst I know this is "CITR" I figure a few people might be interested in it. I'll probably skip a lot of the smaller things so forgive me if it seems the story skips along a bit, it's been a while in the works.

It all started in october 2011, I had made the decision to but a weekend car that I could race with the boys (ffamily). The base was simple, a civic. So I went looking and a few days later I found the perfect base.



A 91 Eg civic with a b16 swap and carbon bonnet and fujitsubo catback. I bit the bullet and purchased the car, 10 hours later my friend Alex and I had road tripped from rockhampton to brisbane and I was now the owner of a civic!





First thing I did was buy the essentials and fit some parts I already had from my dc2.
Bushes, koyo radiator and suspension parts, Baffled sump + 5zigen headers+ highflow cat, MFactory Coilovers, 282 itr setup (dba4000 rotors and endless mx72 pads) AND 949 6UL wheels wrapped in Federal RSR's.









Got everything in and had a month to drive around till my first track day. The day finally came and I was out with my buddy Ash (egb055) in his k20EG. This is the moment that it all began, one you go track you never go back :P




Soon after that day i was hooked! And went out to lakeside raceway for some fun!




After that I bought myself a full cage and made myself a splitter!




Added an oil cooler, catch can, 4.9 final drive and ATS carbon lsd (dont have pics of lsd and FD install)



And spent the rest of the year racing as much as I could

[lil_foy]

By now we are up to late 2012 and i've decided it was time to tidy up the car (paint wasnt the best when I got it and it had faded across the year. So full respray inside and out was done!



I also was worried about all the 6ul's breaking so I switched to the JDMYard buddy club specials (thanks again yonas!)


OH and I bought a j's wing (no pics at the time though)

And to add to the increasing bill I figured I may aswell build a new motor for the new year...

Specs are;
B16b block/head
B18cR Crank
Ek9 cams/gears and valves
Supertech Valve springs and retainers
81.5mm 11:1 Cp pistons and Eagle Rods
Acl Race bearings
Arp Headstuds
New oil pump, etc.
Orc Clutch
It is essentially a forged stock b18cr.






Got the car tuned (made 164hp) and was driving home when all of a sudden steering got really heavy, felt like the wheel were locked. Dropped the gearbox oil when I got home and bam, metal. So we pulled it out next day and..bam! So I ordered a mfactory helical lsd and threw it all back together (luckily because the diff was a clutch type all the exploded internals were contained and nothing else got damaged!



FINALLY it was running perfectly and I took her out for her first big decent drive, this is how she was sitting in street spec.


And a bit of a before and after shot across one year of progress, I smashed my old pb with the b16 (61.6 sprint) with a 59.6 with the b18cr that day!



Went out to the drags to see how it performs and I was pretty stoked with the mph and time! Was never expecting much out of it with the huge camber!



I swapped the tyres from 205/50/15 a048's to 225/50/15 a050's and I dropped another second off my pb to a 58.6 QR Sprint and 62.4 Clubman! Finally doing kswap times in it =)

[lil_foy]

Went out to lakeside and after wasting 2 sessions behind a douche bag in a v8 gemini I got one clean session and did a 62.00, still plenty of time to be gained as I had no ideas what gears i'd need to be using.

So thats pretty much where im up to now, i've got a few updates coming in the next few months so ill keep this updated. Hope you enjoyed!



Here is a full mod list too.


Engine bay:
B16b;
81.5mm 11:1 CP Pistons
Eagle Rods
B18CR Crank
Ek9 Cams
Acl Race Bearings
Arp Headstuds
Cometic Headgasket
Supertech Valve springs & Titanium Retainers
Orc Clutch & Flywheel
DC2 Air box
Polished alloy intake arm
65mm Edelbrock TB (for ITR)
Skunk2 Intake Manifold
P2R gaskets on TB and IM
EK4 TB Cable
Polished OEM Fuel Rail
Polished Edelbrock Inline Fuel filter (has washable element)
Braided fuel line
Koyo Dual Core Alloy Rad
Slim thermo fan
Cusco Radiator Cap
Stainless steel Coolant overflow tank
Converted Manual PS system with lines and stainless steel tank.
Braided clutch line/fittings
Bolt boy engine bay kit
5zigen 4-2-1 b18 headers (2.5" collector)
Magnaflow 2.5" highflow cat
Fujitsubo RM01A Cat back
Spoon Magnetic sump plugs
J's racing engine damper
Jdmyard sump baffle
Mfactory Helical LSD
Osgiken 4.9 final drive
Hondata s300
Hardrace Shifter bushes
Greddy Oil Cooler with custom short lines
Ipg Breather fittings and twin Peterson catch cans (one off back of block, one off rocker cover)

Suspension/Brakes/Wheels:
Dc2r Strut brace
MFactory Modus Agile Coilovers (16kg F /12kg R)(dc2r eyelet)
Whiteline 24mm front sway bar
Asr rear subframe brace
Dc2r Rear swaybar
Dc2r LCA
Dc2 Front hubs
Dc2r 1" Brake booster/Master Cylinder
Dc2r Front calipers
Endless mx72 Front Pads
282mm DBA4000 front rotors
Unknown slotted rear discs
Endless VN9500 read brake pads
ARP Extended Studs
Braided brake lines
Jdmyard 3mm rotor spacer
Mfactory extended ball joints
Hardrace front camber kits, rear camber arms
Hardrace front lca bushes, compliance bushes
15x8 +32 BuddyClub P1 SF Limited Edition OneFive8 (matte black)
225/50/15 Advan a050
10mm Hubcentric Spacers (front), 5mm slip on (rear)

Exterior:
Carbon Fibre Hood (painted
JDM EG6 LIP
JDM EG6 Plastic Headlights
JDM Flat side markers
Raybrig H4H Bulbs
JDM EG6 SiR II Wing
EK Side skirts/front flaps
EG Rear mudflaps
OEM rear window handle
OEM Antenna Blank
Tinted windows
Apr Carbon Mirrors
J's Racing Carbon Wing (mounted to spare eg6 wing)
Custom Front Splitter (track use only)

Interior:
Recaro Pole Positions (black)
Momo monte carlo steering wheel
OEM Si Cluster (with tacho)
Battery kill switch (in cigarette lighter)
Dc2r Style shift knob
KTuned Shifter
Deka lightweight battery behind dash.
Safety 21 7 Point Rollcage (with custom harness bar)
Defi Bf Gauges (oil pressure, oil temp, water temp)

[DC2-PWR]

Came to such a car in short time

Love it mate

[driftpig]

nice car buddy!
where'd you get the air scoop that sits on the front of your bar ( where the foggies should be) for the ram intake ?

[Jongnie]

Good read !

[felixR]

Awesome read. Thanks for sharing Andrew

Good to finally see the build here.

[Norm]

Awesome read dude! Good the see the car used on track!

[ChargeR]

Glad you decided to share your build Andrew.

[DC2-PWR]

Love this photo

[45SET]

I didn't realise you've actually done so much to it Foy!

[lil_foy]

Thanks for all the kind words guys!

I dropped off the front bar above + another front bar + j's racing front lip+ current side skirts to all get painted red. Should have it all back by end of week so finally exterior will be complete! Will have some shots when its done.

[ryry668]

Subscribed!! I loveee EGs with a purpose

[DC2-PWR]

Thanks for all the kind words guys!

I dropped off the front bar above + another front bar + j's racing front lip+ current side skirts to all get painted red. Should have it all back by end of week so finally exterior will be complete! Will have some shots when its done.

nigga what

So keen to see how it will look!!!

[lil_foy]

Dodgey iphone photo for now till I can be bothered to take some decent photos.
J's racing lip fitted and now exterior is complete!!
